Airtac F-TMIC Separate Guide Bracket F-TMICL25X50
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X50 Linear Guide Bracket Specifications
- Model: F-TMICL25X50 (Single Guide Bracket)
- Material: Hardened aluminum alloy 6063-T5
- Load capacity: 1,800N (dynamic), 4,200N (static)
- Precision grade: Normal class (±0.05mm/m)
- Repeating positioning accuracy: ≤±0.01mm
- Mounting hole spacing: 40±0.1mm (longitudinal)
- Seal type: Triple-lip rubber wipers (front/rear)
- Surface treatment: Black anodized (15-20μm thickness)
- Temperature range: -20℃ to +120℃
- Compatible rail: F-TM series 25mm width
- Weight: 350g ±2%
- Dimensions: 50mm(L) × 25mm(W) × 20mm(H)
- Hardness: 65-75 HBW
- Corrosion resistance: 500hr salt spray test passed
Precision-machined linear guide bracket with integrated sealing system, designed for high-rigidity applications requiring dust protection. Features diagonal mounting holes (M6×1.0 thread) for enhanced stability and vibration damping. Includes pre-drilled alignment marks for rapid installation.
- CNC router Z-axis carriage systems
- Automated optical inspection equipment
- 3D printer gantry alignment mechanisms
- Semiconductor wafer handling robots
- Laser cutting machine sliding units
Installation protocol:
Apply 25-35N·m torque during fastening. Use 0.02mm feeler gauge
to verify rail-bracket parallelism. Lubricate contact surfaces
with ISO VG32-grade grease before operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X50 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
