Airtac F-TMIC Separate Guide Bracket F-TMICL25X75
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X75 Individual Guide Unit Technical Details
- Model: F-TMICL25X75
- Type: Linear motion guide with integrated bearing blocks
- Material: Aluminum alloy (anodized surface)
- Load capacity: 1,250N radial / 950N lateral
- Stroke length: 75mm ±0.1mm
- Rail width: 25mm
- Precision grade: C3 (high-precision class)
- Operating temperature: -20℃ to 80℃
- Mounting style: Dual-side flange mounting
- Surface hardness: HV400+
- Recirculating ball system: 4-row circular groove design
- Lubrication: Pre-lubricated with lithium soap grease
- Weight: 450g ±2%
- Dimensions: 75mm(L) × 25mm(W) × 25mm(H)
Precision-engineered linear guide system featuring ultra-low friction coefficients (μ<0.003) and vibration damping properties. The hardened steel rails with chrome plating (3-5μm thickness) ensure wear resistance in continuous operation. Includes built-in dust seals (NBR material) on both ends for particle protection.
- High-speed pick-and-place robotic arms
- Precision CNC tooling equipment Z-axis guides
- Semiconductor wafer handling systems
- Automated optical inspection (AOI) machines
- 3D printer gantry alignment systems
Installation protocol:
Requires torque-controlled mounting (3.5-4.2N·m for M5 screws) with
parallelism error <0.02mm/m. Perform running-in operation at 30%
max speed for 50 cycles before full load operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X75 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
