Airtac F-TMIC Separate Guide Bracket F-TMICM16X100
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X100 Linear Guide Bracket Specifications
- Model: F-TMICM16X100
- Type: Independent guide bracket for cylinder alignment
- Compatible cylinder bore: Ø16mm
- Stroke length: 100mm
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Hard anodized (Silver)
- Mounting hole spacing: 38mm (center-to-center)
- Bolt size: M5×0.8 mounting screws (4 places)
- Load capacity: 220N dynamic / 550N static
- Friction coefficient: ≤0.15 (with regular lubrication)
- Operating temperature: -20℃ to +80℃
- Weight: 0.48kg ±2%
- Dimensions: 150mm(L) × 42mm(W) × 28mm(H)
- Guide rod diameter: Ø12h6 precision ground
- Parallelism tolerance: ≤0.05mm/100mm
- Surface hardness: HV400±20
Precision-machined guide bracket featuring dual linear ball bushings for smooth axial movement. Includes integrated wiper seals to prevent particulate ingress, with hardened guide rods for extended service life. Requires periodic lubrication (recommended interval: 500km travel distance).
- Precision alignment for pneumatic cylinders in pick-and-place systems
- Vertical Z-axis support in CNC tool changers
- Guiding mechanism for automated packaging seal bars
- Linear motion stabilization in semiconductor handling robots
- Support structure for vacuum picker end effectors
Installation protocol:
Mount using grade 8.8 or higher fasteners with 8-10Nm torque.
Perform parallel alignment check using dial indicator (max allowable deviation: 0.1mm across stroke length).
Apply lithium-based grease (NLGI #2) to guide rods during assembly.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X100 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
