Airtac F-TMIC Separate Guide Bracket F-TMICM16X125
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X125 Individual Guide Bracket Specifications
- Model: F-TMICM16X125
- Type: Micro linear guide system (single axis)
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Rail width: 16mm
- Effective stroke: 125mm
- Static load capacity: 3.2kN (C0)
- Dynamic load capacity: 1.8kN (C)
- Precision grade: Normal (C) / High (H) optional
- Mounting hole pattern: 30mm × 60mm rectangular array
- Surface treatment: Black oxide coating (5-8μm)
- Operating temperature: -20℃ to 120℃
- Weight: 680g ±2%
- Dimensions: 165mm(L) × 22mm(W) × 18mm(H)
- Hardness: HRC 58-62 (rail), HRC 54-58 (block)
- Dust protection: Standard wiper seals (IP40)
Precision-engineered miniature linear guide featuring optimized ball recirculation design for smooth motion control. The hardened steel construction ensures minimal deformation under lateral forces, with preloaded ball bearings reducing backlash to ≤0.01mm. Compatible with automated lubrication systems through integrated grease ports.
- PCB drilling/spindles in electronics manufacturing
- Optical lens positioning stages
- Semiconductor wafer handling robots
- Precision syringe pumps in medical devices
- High-speed pick-and-place mechanisms
Installation note:
Requires torque-controlled tightening (1.2-1.5Nm) with M4 mounting screws.
Parallelism tolerance between rails must be ≤0.02mm/100mm. Lubricate with ISO VG15-32 grease before initial operation.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X125 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
