Airtac F-TMIC Separate Guide Bracket F-TMICM16X150
$63.96
Regular price
$71.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICM16X150
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting. Apply supplemental lubrication every 50km of travel.
Compatible with AIRTAC MMF-16 series flange blocks.
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X150 Individual Guide Unit Specifications
- Model: F-TMICM16X150
- Type: Linear motion guide with integrated bearing
- Material: Aluminum alloy body with hardened steel shafts
- Shaft diameter: 16mm (±0.005mm precision)
- Effective stroke: 150mm
- Max load capacity: 850N (dynamic), 1,700N (static)
- Mounting style: Side-mount with M6 threaded holes
- Operating temperature: -10℃ to 80℃
- Surface treatment: Black anodized (Aluminum), Chrome-plated (Shaft)
- Weight: 0.28kg (excluding accessories)
- Dimensions: 150mm(L) × 28mm(W) × 28mm(H)
- Repeat positioning accuracy: ±0.01mm
- Lubrication: Pre-lubricated with lithium grease
Precision linear guide unit designed for high-accuracy reciprocating motion systems. Features dual hardened steel shafts with low-friction polymer bearings, optimized for vertical/horizontal installations. Includes anti-corrosion treatment for industrial environments.
Typical Applications:
- Automated pick-and-place equipment Z-axis guidance
- 3D printer gantry stabilization systems
- Medical analyzer sliding mechanisms
- Semiconductor wafer handling robots
- Precision grinding machine tool guides
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting. Apply supplemental lubrication every 50km of travel.
Compatible with AIRTAC MMF-16 series flange blocks.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X150 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
