Airtac F-TMIC Separate Guide Bracket F-TMICM16X200
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X200 Individual Guide Bracket Technical Details
- Model: F-TMICM16X200
- Type: Linear guideway support block (individual type)
- Bolt size: M16×1.5 thread
- Stroke length: 200mm
- Static load capacity: 12.5kN (radial), 9.8kN (reverse radial)
- Dynamic load capacity: 6.3kN (radial), 4.9kN (reverse radial)
- Material: Carbon steel with black oxide coating
- Hardness: 58-62 HRC (guide rail contact surfaces)
- Precision grade: Normal grade (±0.1mm/m), High precision (±0.05mm/m) optional
- Operating temperature: -20℃ to 80℃
- Surface roughness: Ra 0.8μm (sliding surfaces)
- Weight: 1.25kg ±2%
- Dimensions: 200mm(L) × 42mm(W) × 34mm(H)
- Mounting hole spacing: 160mm (longitudinal), 30mm (transverse)
Precision-machined linear motion component with hardened contact surfaces, designed for high-rigidity applications requiring stable sliding motion. Features oil-retaining grooves for improved lubrication retention and anti-corrosion treatment for industrial environments. Compatible with standard M16 mounting hardware.
- CNC machine tool Z-axis support systems
- Automated packaging equipment linear guides
- 3D printer gantry stabilization
- Material handling system carriage blocks
- Semiconductor manufacturing stage supports
Installation protocol:
Apply lithium-based grease to sliding surfaces before assembly.
Use torque wrench (45-50N·m) for M16 fasteners. Maintain
parallelism within 0.02mm/m during rail alignment.
Requires periodic lubrication every 200 operating hours.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X200 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
