Airtac F-TMIC Separate Guide Bracket F-TMICM16X25
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X25 Individual Guide Bracket Technical Details
- Model: F-TMICM16X25
- Type: Linear motion guide system component
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Inner diameter: 16mm ±0.003mm
- Outer diameter: 25mm ±0.005mm
- Total length: 25mm ±0.1mm
- Static load capacity: 1,250N
- Dynamic load capacity: 680N
- Hardness: HRC 58-62 surface hardness
- Mounting style: Flange-mounted with M4x0.7 threaded holes
- Temperature range: -20℃ to 120℃ (continuous operation)
- Surface treatment: Black oxide coating (5-8μm thickness)
- Seal type: Integrated dust-proof rubber seals
- Compatible rail: MGN/MGW12 series linear guides
- Weight: 0.12kg ±2%
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H)
Precision-engineered linear guide carriage featuring preloaded ball bearings for zero-backlash operation in high-accuracy applications. The hardened steel construction ensures 50km+ service life under standard loads. Includes built-in grease retention grooves and dual-side sealing for contamination resistance.
- CNC machine tool X/Y-axis positioning systems
- 3D printer extruder carriage assemblies
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling robots
- Precision laser cutting head mounts
Installation protocol:
Use torque-controlled wrench (0.7-0.9N·m) for mounting screws.
Align within 0.02mm parallel tolerance relative to rail.
Apply lithium soap-based grease (NLGI #2) during assembly.
| Property | Property Value |
|---|---|
| sku | F-TMICM16X25 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
