Airtac F-TMIC Separate Guide Bracket F-TMICM16X75
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICM16X75 Individual Guide Bracket Specifications
- Model: F-TMICM16X75
- Type: Linear motion guide system component
- Material: Aluminum alloy (AL6063-T5)
- Surface treatment: Hard anodized (25-30μm thickness)
- Ball diameter: 3.175mm (precision grade G10)
- Preload level: Medium (C2 class)
- Static load capacity: 12.5kN (radial), 9.8kN (reverse radial)
- Dynamic load capacity: 8.4kN (radial), 6.3kN (reverse radial)
- Mounting hole pattern: 16mm bore spacing (M6 threaded holes)
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-lubricated with KANTHALUBE PG grease
- Weight: 420g ±2% (bare unit)
- Dimensions: 75mm(L) × 32mm(W) × 24mm(H)
- Parallelism tolerance: ≤0.015mm/m
- Surface roughness: Ra 0.8μm (rolling surfaces)
Precision-machined guide bracket with integrated recirculating ball system, designed for high-accuracy linear motion applications. Features corrosion-resistant anodized coating and optimized ball groove geometry for smooth operation under heavy loads. Compatible with standard 16mm diameter shafts (h6 tolerance grade).
- CNC machine tool slides
- Automated optical inspection (AOI) equipment
- 3D printer Z-axis stabilization systems
- Semiconductor wafer handling robots
- Precision grinding machine carriages
Installation note:
Apply 68-72 N·m torque during M6 screw fastening. Use 0.02mm feeler gauge
for parallelism verification. Requires periodic relubrication every 500km
of travel or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | F-TMICM16X75 |
| Bore Diameter | 16mm |
| Bearing Category | Bronze Bushing |
