Airtac F-TMIL Guide Unit Assembly F-TMIL12X50
$78.13
Regular price
$85.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMIL12X50
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with pneumatic cylinder technology;
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
Installation tip:
Apply Loctite 243 to mounting screws and torque to 1.2N·m.
Perform alignment verification using dial indicator (max 0.05mm runout allowed).
Lubricate with ISO VG32 hydraulic oil during maintenance.
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X50 Linear Guide Bracket Kit Technical Details
- Model: F-TMIL12X50
- Type: Integrated linear motion guide assembly
- Bore diameter: 12mm (precision ground)
- Stroke length: 50mm (effective travel)
- Max load capacity: 350N (axial), 150N (radial)
- Material: Anodized aluminum alloy (6063-T5)
- Bearing type: Pre-lubricated bronze bushings
- Surface hardness: HRC 58-62 (shaft)
- Operating temperature: -30℃ to 120℃
- Repeat accuracy: ±0.02mm
- Mounting hole pattern: 25mm × 25mm (M4 threaded)
- Weight: 220g ±5%
- Dimensions: 78mm(L) × 34mm(W) × 34mm(H)
Complete linear guidance solution combining hardened shaft and anti-drift bracket, featuring zero-backlash design with 5μm surface roughness on critical contact areas. Includes pre-mounted wear-resistant dust seals and alignment shims for vertical/horizontal installation.
Ideal for:
- Precision XY-axis positioning in CNC tool changers
- Automated test equipment probe movement systems
- Food packaging machine stopper mechanisms
- Semiconductor wafer handling robots
- 3D printer extruder carriage assemblies
Installation tip:
Apply Loctite 243 to mounting screws and torque to 1.2N·m.
Perform alignment verification using dial indicator (max 0.05mm runout allowed).
Lubricate with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X50 |
| Bore Diameter | 12mm |
| Stroke | <50mm> |
