Airtac F-TMIL Guide Unit Assembly F-TMIL12X75
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X75 Linear Guide Unit Complete Package Specifications
- Model: F-TMIL12X75
- Type: Linear motion guide with integrated bearing carriage
- Rail material: Cold-drawn carbon steel (HRC58-62 surface hardness)
- Carriage material: Aluminum alloy with hardened steel balls
- Bore diameter: Ø12mm
- Stroke length: 75mm
- Dynamic load capacity: 1,470N
- Static load capacity: 3,430N
- Mounting hole spacing: 30mm ±0.1 (longitudinal), 24mm ±0.05 (transverse)
- Weight: 680g ±2%
- Dimensions: 155mm(L) × 24mm(W) × 18.5mm(H)
- Surface treatment: Nickel-plated rail, hard anodized carriage
- Operating temperature: -20℃ to 100℃
- Preload level: Medium (C2 class)
- Recirculation system: 4-row circular contact design
Precision-engineered linear guide system combining a hardened steel rail with preloaded ball bearings in a compact aluminum carriage. Features integrated mounting holes for direct machine integration and corrosion-resistant surface treatments. Includes pre-installed end stoppers and lubrication ports for maintenance.
- CNC router Z-axis stabilization systems
- Automated sliding door mechanisms
- 3D printer gantry alignment
- Medical imaging equipment drawers
- Semiconductor wafer handling robots
Installation note:
Use M4×8mm flat-head screws (recommended torque 1.2N·m) for mounting.
Apply lithium-based grease through lubrication ports every 500km of travel.
Maintain parallelism within 0.05mm/m during rail alignment.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X75 |
| Bore Diameter | 12mm |
| Stroke | 75mm |
