Airtac F-TSAI Individual Guide Holder F-TSAIL100X100
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X100 Linear Guide Solo Carriage Unit Specifications
- Model: F-TSAIL100X100
- Type: Single-axis linear guide carriage (separate type)
- Material: Aluminum alloy ADC12
- Mounting hole pattern: 100mm × 100mm square
- Height: 30mm ±0.2
- Weight: 0.82kg ±3%
- Dimensions: 100mm(L) × 100mm(W) × 30mm(H)
- Dynamic load capacity: 60kg (C value)
- Static load capacity: 150kg (C0 value)
- Operating temperature: -20℃ to 80℃
- Surface treatment: Black anodized (12μm thickness)
- Seal material: Polyurethane wipers with stainless steel scrapers
- Ball circuit design: 4-row circular arc groove
- Preload class: Normal clearance (C0)
- Protection rating: IP54 standard sealing
Precision-engineered standalone guide carriage featuring optimized ball recirculation for smooth linear motion. The hardened steel rails with chrome plating (HRC58-62) ensure wear resistance, while the aluminum body reduces inertial mass. Compatible with 15mm width linear guide rails (e.g., HGH15CA series). Includes pre-drilled mounting holes with M5 thread size for flexible installation.
- High-speed pick-and-place mechanisms in SMT equipment
- Z-axis carriage for CNC engraving machines
- Precision positioning stages in semiconductor handling
- Automated inspection equipment slides
- Medical imaging device component carriers
Installation note:
Apply lithium-based grease (No.2 consistency) to rail surfaces before assembly.
Use torque-controlled tightening at 1.2-1.5N·m for mounting screws. Maintain parallel
alignment within 0.05mm/m during rail installation.
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X100 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
