Airtac F-TSAI Individual Guide Holder F-TSAIL100X200
$650.21
Regular price
$657.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TSAIL100X200
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The F-TSAI Series Guide Unit with Integrated Cylinder features:
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
Installation note:
Use torque-controlled wrench (recommended 5.4 N·m for M6 bolts) and align within 0.05mm/m straightness tolerance.
Apply lithium soap-based grease every 500km travel distance.
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X200 Single Axis Guide Unit Specifications
- Model: F-TSAIL100X200
- Type: Linear motion guide with integrated rail & block
- Material: Aluminum alloy (AL6063-T5) with hard anodized surface
- Load capacity:
- Dynamic: 1,200 N
- Static: 2,800 N
- Precision grade: Normal class (≤50μm/300mm running parallelism)
- Ball diameter: 3.175mm (G10 chromium steel)
- Recirculation system: 4-row circular groove design
- Sealing: Triple wiper seals + end scrapers
- Weight: 3.8 kg ±2%
- Dimensions:
- Length: 200mm
- Width: 100mm
- Height: 34.5mm (rail) / 24mm (block)
- Mounting hole pattern: M6 threaded holes @ 40mm pitch
- Operating temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated with VG32 grease
Heavy-duty linear guide system combining high rigidity and smooth motion characteristics. Features corrosion-resistant construction with hardened raceways, optimized for vertical/horizontal mounting in dirty environments. Includes alignment marks for simplified installation.
Typical Applications:
- CNC router Z-axis support mechanisms
- Automated material handling carts
- Industrial printer carriage systems
- Packaging machine vertical lifts
- Semiconductor wafer transfer units
Installation note:
Use torque-controlled wrench (recommended 5.4 N·m for M6 bolts) and align within 0.05mm/m straightness tolerance.
Apply lithium soap-based grease every 500km travel distance.
Compatible accessories:
- Mounting brackets: F-MB60 series
- End dampers: F-ED35 shock absorbers
- Protective covers: F-PC1000 bellows
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X200 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
