Airtac F-TSAI Individual Guide Holder F-TSAIL100X300
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X300 Single Axis Guide Bracket Specifications
- Model: F-TSAIL100X300
- Type: Linear motion guide support block (single axis)
- Material: Aluminum alloy AL6063-T5
- Surface treatment: Anodized (black)
- Max horizontal load capacity: 500N
- Max vertical load capacity: 800N
- Mounting hole spacing: 100mm × 300mm (±0.1mm tolerance)
- Compatible rail width: 20mm
- Weight: 2.5kg ±3%
- Dimensions: 350mm(L) × 100mm(W) × 50mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV 80±5
- Vibration resistance: 10-2000Hz, 15m/s² max
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined guide bracket featuring dual-row angular contact structure for enhanced moment resistance. The hardened stainless steel rolling elements ensure smooth linear motion with repeat positioning accuracy of ±0.01mm. Integrated oil retention grooves allow continuous lubrication, reducing wear in high-cycle applications.
- CNC tool changer sliding mechanisms
- Automated optical inspection (AOI) equipment
- 3D printer X/Y axis stabilization
- Semiconductor wafer handling robots
- Laser cutting machine linear guides
Installation note:
Use torque-controlled wrench (recommended 5.4N·m) for M8 mounting bolts.
Apply thread-locking adhesive and perform parallel alignment verification
using dial indicator (max 0.05mm/m deviation allowed).
⚠️ Storage requirement: Maintain in dry environment (RH＜60%) with anti-rust paper wrapping when not installed. Avoid direct contact with alkaline cleaning agents.
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X300 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
