Airtac F-TSAI Individual Guide Holder F-TSAIL100X350
$681.59
Regular price
$689.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TSAIL100X350
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The F-TSAI Series Guide Unit with Integrated Cylinder features:
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
Installation protocol:
Apply initial lubrication (VG32 grease) to all ball tracks before assembly.
Torque mounting bolts to 5.2 N·m using cross-tightening sequence.
Avoid axial misalignment exceeding 0.05mm/m during rail pairing.
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X350 Linear Guide Carriage Specifications
- Model: F-TSAIL100X350
- Type: Independent linear guide carriage (non-driven unit)
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Ball circuit system: 4-row circular arc contact design
- Dynamic load rating: 12.5 kN
- Static load rating: 24.8 kN
- Rail width compatibility: 15-25mm guide rails
- Preload level: Normal clearance (C0 class)
- Dimensions: 100mm(L) × 34mm(W) × 23.5mm(H)
- Weight: 0.68 kg ±2%
- Mounting hole pattern: 80mm longitudinal spacing (M6 threaded holes)
- Operating temperature: -20℃ to 100℃ (lubricant dependent)
- Surface hardness: HRC 58-62 (raceway)
- Sealing: Triple labyrinth seal with grease retention
Precision-engineered linear motion carriage featuring optimized stress distribution through X-axis symmetrical design. The hardened raceways and chrome steel balls ensure smooth reciprocating motion with PV values up to 2.5 MPa·m/s. Includes anti-creep side locks for secure rail attachment.
Typical Applications:
- High-speed pick-and-place Z-axis mechanisms
- CNC tool changer sliding units
- Semiconductor wafer handling robots
- Automated optical inspection (AOI) stages
- Food packaging vertical lift systems
Installation protocol:
Apply initial lubrication (VG32 grease) to all ball tracks before assembly.
Torque mounting bolts to 5.2 N·m using cross-tightening sequence.
Avoid axial misalignment exceeding 0.05mm/m during rail pairing.
Lifecycle management:
Relubrication interval: 500km travel or 6 months (whichever comes first).
Wear limit: Replace when vertical play exceeds 0.15mm under 10N preload.
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X350 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
