Airtac F-TSAI Individual Guide Holder F-TSAIL100X400
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X400 Individual Guide Unit Specifications
- Model: F-TSAIL100X400
- Type: Linear motion guide with integrated bearing blocks
- Bore diameter: 100mm
- Stroke length: 400mm (±200mm)
- Material: Anodized aluminum alloy (rail) + Carbon steel (shaft)
- Max load capacity: 1,200N (radial), 800N (moment load)
- Mounting style: Through-hole flange mounting
- Operating temperature: -10℃ to 80℃
- Surface hardness: HRC 58-62 (shaft)
- Precision grade: C7 class (≤0.1mm/m straightness)
- Seal type: Triple-lip polyurethane wipers
- Weight: 2.5kg (rail only), 3.8kg (complete assembly)
- Dimensions: 400mm(L) × 120mm(W) × 100mm(H)
Heavy-duty linear guide system featuring dual bearing blocks with adjustable preload, designed for high moment load applications. The chrome-plated shaft and hardened rail provide exceptional wear resistance, while integrated dust seals maintain lubrication integrity in contaminated environments.
- Precision CNC tool changers
- Automated material handling systems
- Industrial printing press carriage guides
- Food processing linear actuators
- Semiconductor wafer handling robots
Installation note:
Requires parallel alignment within 0.05mm/m using laser alignment tools.
Apply lithium soap-based grease (NLGI #2) to shaft before operation.
Torque mounting bolts to 18-22N·m in crisscross pattern.
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X400 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
