Airtac F-TSAI Individual Guide Holder F-TSAIL100X450
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X450 Individual Guide Bracket Specifications
- Model: F-TSAIL100X450
- Type: Linear Motion Single Axis Guide Bracket
- Material: Aluminum Alloy (6063-T5)
- Surface Treatment: Anodized (Silver/Gray)
- Dynamic Load Capacity: 1,200N
- Static Load Capacity: 2,400N
- Applicable Shaft Diameter: Ø16-20mm
- Mounting Type: Horizontal/Vertical/Ceiling
- Weight: 2.8kg ±3%
- Dimensions: 450mm(L) × 100mm(W) × 48mm(H)
- Operating Temperature: -10℃ to 80℃
- Precision Grade: P5 (High Precision)
- Repeat Positioning Accuracy: ±0.02mm
- Lubrication: Pre-lubricated with Molykote EM-30L grease
Heavy-duty linear guide system featuring dual V-groove design for precise alignment compensation. Integrated sealing strips prevent particulate ingress (IP54 equivalent). Optimized for high-cycle applications with hardened stainless steel guide shafts (optional). Includes pre-drilled mounting holes with M6 thread spacing.
- Automated material handling systems
- Precision CNC tool guide rails
- 3D printer Z-axis stabilization
- Medical imaging equipment slides
- Semiconductor wafer handling robots
Installation note:
Use 0.02mm feeler gauge to verify parallel alignment during assembly.
Re-torque mounting bolts to 4.5N·m after 50hrs of initial operation.
- Optimal with AirTAC SHS20 linear shafts
- Compatible with AMR/AGV drive systems
- Requires minimum C3 grade ball bearings
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X450 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
