Airtac F-TSAI Individual Guide Holder F-TSAIL100X500
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL100X500 Linear Guide Single Rail Specifications
- Model: F-TSAIL100X500
- Type: Single-axis aluminum profile guide rail
- Material: 6063-T5 aluminum alloy (hard anodized)
- Effective length: 500mm ±0.1mm
- Profile width: 100mm
- Slot width: 8.2mm (M6 compatible)
- Mounting hole spacing: 50mm pitch (M6 threaded)
- Load capacity:
- Dynamic: 1,200N (radial)
- Static: 3,500N (radial)
- Surface roughness: Ra 0.8μm (sliding surface)
- Parallelism: ≤0.02mm/100mm
- Weight: 2.45kg ±3%
- Dimensions: 500mm(L) × 100mm(W) × 40mm(H)
- Temperature range: -20℃ to 120℃
- Surface treatment: Black anodized (15-20μm thickness)
- Sealing: Integrated NBR wipers (replaceable)
Precision-machined linear guide system designed for high-accuracy sliding mechanisms. Features dual V-groove alignment channels and hardened stainless steel bearing surfaces. The modular design allows daisy-chaining multiple units for extended travel. Includes pre-drilled mounting holes with counterbores for flush fastener installation.
- CNC router Z-axis stabilization systems
- Automated optical inspection equipment
- 3D printer gantry alignment
- Semiconductor wafer handling robots
- Medical imaging device sliding mechanisms
Installation note:
Clean rail surfaces with isopropyl alcohol before assembly.
Use torque-controlled wrench (1.2-1.5N·m for M6 bolts)
and apply lithium-based grease in bearing channels.
Avoid thermal expansion by maintaining 23±5℃ during installation.
| Property | Property Value |
|---|---|
| sku | F-TSAIL100X500 |
| Bore Diameter | 100mm |
| Bearing Category | Linear Bearing |
