Airtac F-TSAI Individual Guide Holder F-TSAIL32X100
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL32X100 Linear Guide Bracket Specifications
- Model: F-TSAIL32X100
- Type: Single-axis linear guide support block
- Bore diameter: 32mm
- Stroke length: 100mm
- Material: Aluminum alloy (AL6063-T5)
- Surface treatment: Hard anodized (25μm thickness)
- Dynamic load capacity: 1,850N
- Static load capacity: 3,200N
- Precision grade: P-class (±0.05mm/m)
- Operating temperature: -20℃ to 80℃
- Mounting hole pattern: 60mm × 60mm square
- Weight: 0.52kg
- Dimensions: 100mm(L) × 80mm(W) × 80mm(H)
- Sealing: Integrated wiper seals (NBR material)
- Lubrication: Pre-greased (Molykote EM-30L)
Precision-machined linear motion support block designed for high-rigidity applications. Features dual-row ball bearing configuration with 4-point contact design for smooth linear movement and minimal deflection. Compatible with standard 32mm diameter linear shafts, includes corrosion-resistant coating for industrial environments.
- CNC router Z-axis support systems
- Automated material handling conveyors
- 3D printer gantry stabilization
- Semiconductor wafer handling robots
- Laser cutting machine linear guides
Installation note:
Requires parallel alignment within 0.02mm/m using precision level during mounting.
Torque mounting bolts to 4.5N·m in crisscross pattern. Relubricate every 500km of travel.
| Property | Property Value |
|---|---|
| sku | F-TSAIL32X100 |
| Bore Diameter | <32 mm> |
| Bearing Category | Linear Bearing |
