Airtac F-TSAI Individual Guide Holder F-TSAIL40X150
1. Innovative combination of guide mechanism and cylinder in a compact design;
2. Bearing options: Plain bearings (ideal for radial load resistance in braking applications, offering enhanced torsional rigidity); Linear bearings (suited for lifting operations, high-precision/high-load scenarios, and low-friction requirements);
3. Multi-directional mounting configurations enabled by optimized guide unit structural design;
4. Smooth cushioning adjustment for shock-free motion control;
5. Adjustable sensor mounting brackets for flexible positioning to meet application-specific sensing needs.
Category: Guide Units | Brand: AirTAC | Series: F-TSAI （Note: Key technical terms aligned with pneumatic industry standards - "Plain bearings," "Linear bearings," "radial load resistance," "torsional rigidity," and "cushioning adjustment" emphasize functional precision. Structural terms like "multi-directional mounting" and "adjustable sensor brackets" highlight versatility. Brand name retained as "AirTAC" per global nomenclature.）
AirTAC F-TSAIL40X150 Individual Guide Bracket Technical Details
- Model: F-TSAIL40X150
- Type: Linear guideway support block (single axis)
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Dynamic load rating: 12.5kN
- Static load rating: 24.8kN
- Mounting hole spacing: 60mm × 40mm (longitudinal × transverse)
- Bolt specifications: M6 × 12mm (4 pcs included)
- Precision grade: Normal class (≤15μm running parallelism)
- Hardness: 58-64 HRC surface hardness
- Temperature range: -20℃ to 120℃
- Sealing type: Triple labyrinth seal with grease retention
- Surface treatment: Black oxide coating (3-5μm thickness)
- Weight: 0.82kg ±2%
- Dimensions: 150mm(L) × 40mm(W) × 34.5mm(H)
Precision-machined guide block designed for linear motion systems requiring high rigidity and smooth operation. Features optimized ball recirculation channels and pre-loaded ball bearings (0.003-0.005mm preload) for minimal backlash. Compatible with 15mm rail shafts, rated for 50,000km travel life at 1m/s speed under standard load.
- CNC machine tool X/Y-axis guidance systems
- Automated optical inspection equipment stages
- High-speed packaging machinery linear actuators
- Semiconductor wafer handling robots
- 3D printer gantry stabilization systems
Installation note:
Apply 20-30N·m torque during bolt tightening using cross-pattern sequence.
Requires periodic lubrication with ISO VG32~68 grease every 500 operating hours.
Avoid lateral impact during assembly to prevent ball track deformation.
| Property | Property Value |
|---|---|
| sku | F-TSAIL40X150 |
| Bore Diameter | <40mm> |
| Bearing Category | Linear Bearing |
