AirTAC GFC200-06 Combination Unit (GFC20006F1WK)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006F1WK) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
About the AirTAC GFC200-06 Combination Unit (GFC20006F1WK)
The AirTAC GFC series is a two-piece air preparation set: a filter regulator in one body plus a separate lubricator, so the compressed air is cleaned, regulated and oil-misted in one installation. This GFC20006F1WK is the 200 size with a PT1/8 port, a 5 um filter element, the default differential-pressure drain, an embedded square pressure gauge scaled in MPa, and a reverse (check) valve fitted. Maximum working pressure is 1.0 MPa (145 psi); with the differential-pressure drain the regulator adjusts 0.15-0.9 MPa (20-130 psi). The polycarbonate bowls suit -5 to 70 C (non-freezing) air.
This is a genuine AirTAC part. The GFC family also comes in 300, 400 and 600 sizes with larger ports, and the catalogue options include manual or automatic drains, the 40 um standard element, square or round gauges in MPa, psi or bar scales, and G (BSPP) or NPT threads. Flow is published as curves rather than a single rating, so ask us to confirm flow and datasheet figures for your application.
AirTAC GFC200-06 Combination Unit (GFC20006F1WK) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006F1WK) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006F1WK)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006F1WK) Is Used
Electronics pick-and-place line
Feeds cleaned, regulated and lubricated air to small gripper cylinders and miniature valves, where the 5 um element guards fine orifices and the check valve holds the circuit against backflow.
Furniture assembly cell
Supplies the shop-air drop for pneumatic screwdrivers and nail guns: the filter removes water and grit, the regulator holds a set working pressure, and the lubricator mists the tool air motors.
Benchtop pneumatic clamping fixture
Keeps a small machining-cell clamping circuit at a stable, gauge-monitored pressure, with the check valve helping the clamp hold its setting in the supply line.
Is the AirTAC GFC200-06 Combination Unit (GFC20006F1WK) the Right Set?
The 200 size with its PT1/8 port is the smallest step in the GFC range; if your circuit draws more air, move up to GFC300 with a 1/4 in port. This unit carries the default differential-pressure drain, which suits steady-running supply; specify A (automatic) or M (manual) in the code if your duty or drain access calls for it - note the manual-drain version widens the adjust range down to 0.05-0.9 MPa (7-130 psi). The 5 um element here protects finer components; the 40 um standard element suits general circuits. The embedded square gauge is scaled in MPa, and the K code adds a reverse (check) valve. PT is the standard thread; G (BSPP) or NPT can be ordered as catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006F1WK) FAQ
AirTAC publishes G-series flow as curves, not as a single rated figure, so we do not quote one number here. Tell us your line's air demand and we will confirm the flow from the datasheet for this 200 size with its PT1/8 port before you order.
This model carries the default differential-pressure drain, for which the regulator adjusts 0.15-0.9 MPa (20-130 psi). Manual-drain versions of the same set widen the range down to 0.05-0.9 MPa (7-130 psi); you choose the drain type with the letter in the code.
