Airtac GTC Air Treatment Combination GTC20006LWK
$73.27
Regular price
$80.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GTC20006LWK
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. This product adopts the GA200 series compact PC bowl specification, retaining all GA200 series characteristics while featuring these unique advantages:
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Pre-charge lubricator with ISO VG32 oil before operation.
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006LWK Technical Specifications
- Model: GTC20006LWK
- Type: Filter-Regulator-Lubricator (FRL) combination unit
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.15–1.0 MPa
- Filtration rating: 5μm (with auto-drain)
- Pressure regulation range: 0.05–0.85 MPa
- Oil cup capacity: 200cc (transparent polycarbonate)
- Temperature range: 0℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (filter bowl: impact-resistant PC)
- Weight: 0.9kg (dry, without lubricant)
- Dimensions: 180mm(H) × 100mm(W) × 130mm(D)
- Thread standard: BSPP (G thread)
- Maximum flow rate: 3,500 L/min (ANR)
- Pressure gauge: 1/8" dial type (MPa scale)
Modular FRL unit combining precision air preparation stages with visible oiler function. Features twist-lock bowl design for quick maintenance and dual-scale pressure gauge (MPa/psi). The transparent oil cup includes anti-backflow valve and drip-rate adjuster (1-5 drops/min).
Typical Applications:
- Pneumatic production line air preparation systems
- CNC machine tool pneumatic circuits
- Industrial robot end-effector supply lines
- Packaging machinery compressed air conditioning
- Automotive assembly pneumatic tool stations
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Pre-charge lubricator with ISO VG32 oil before operation.
Maintenance cycle:
Drain filter bowl weekly under normal operation (daily in high-humidity environments).
Replace filter element every 6-8 months.
Refill lubricant when oil level drops below 1/3 capacity.
| Property | Property Value |
|---|---|
| sku | GTC20006LWK |
| Port Size | PT1/8 |
