Airtac GV Slow Start Valve GV20006JNB
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow-Start Valve GV20006JNB Technical Details
- Model: GV20006JNB (GV2000 series)
- Function: 5/3-way closed center, slow-start pneumatic valve
- Port configuration: 5 ports (P, A, B, EA, EB) / 3 positions
- Port size: G1/4 (BSPP thread standard)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Cv value: 1.6 (flow coefficient at 0.5 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (standard), Class F insulation
- Response time: 30ms (ON)/25ms (OFF) typical
- Weight: 480g ±3% (including coil)
- Dimensions: 58mm(W) × 45mm(H) × 128mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Protection class: IP67 (dust/water resistant)
- Manual override: Optional paddle-type actuator
Precision-engineered slow-start valve with progressive flow control, featuring soft-start functionality to prevent mechanical shock in pneumatic systems. The three-position design allows intermediate circuit holding, while the dual exhaust ports (EA/EB) enable customized exhaust speed adjustment. Constructed with anodized aluminum body and brass fittings for chemical resistance.
- Clamping force control in injection molding machines
- Precision positioning systems for semiconductor handling robots
- Speed-sensitive assembly line actuators
- Packaging machinery with fragile product handling
- Test bench pressure profiling systems
Installation guidelines:
Mount horizontally with ports facing downward to prevent debris accumulation.
Use 5μm filtration for compressed air. For optimal slow-start performance,
adjust the built-in flow control screw (2.5mm hex key required) with ¼ turn
increments while monitoring actuator response.
| Property | Property Value |
|---|---|
| sku | GV20006JNB |
| Pressure Gauge Code | Without attached table |
| Port Size | PT1/8 |
| Bracket Code | Without bracket |
| Coil Voltage | DC24V |
