Airtac GV Slow Start Valve GV20006NA
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV20006NA Slow-Start Valve Technical Details
- Model: GV20006NA
- Type: 5/3-way closed center (slow-start proportional control)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz)
- Response time: 50ms open / 200ms soft-close
- Weight: 320g ±5% (with coil)
- Dimensions: 78mm(L) × 45mm(W) × 35mm(H)
- Seal material: FKM fluorocarbon (standard), EPDM optional
- Temperature range: -5℃ to 60℃ (extended to 80℃ with FKM seals)
- Power consumption: 2.8W (DC24V), 3.5VA (AC110V)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (PT1/4), 9mm (G1/8)
- Hysteresis: ≤10% F.S.
Precision slow-actuation valve with progressive flow control, featuring anti-vibration design and shock-absorbing sprod assembly. The GV20006NA incorporates a pilot-operated two-stage mechanism with pressure compensation, achieving ±3% repeatability. Compatible with ISO 15407-1 standards, requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Robotic gripper force modulation systems
- Injection molding machine clamp control
- Elevator door safety mechanisms
- Textile tensioning equipment
- Semiconductor wafer handling robots
Installation guidelines:
Mount horizontally with pilot port facing downward. Allow 30-second
pre-charge before initial operation. Lubricate monthly with ISO VG32
pneumatic oil when used in dry environments.
Critical note:
Do NOT use with oxygen media. Maximum permissible instantaneous
current: 0.45A. Always install downstream moisture separator.
| Property | Property Value |
|---|---|
| sku | GV20006NA |
| Pressure Gauge Code | Without attached table |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | AC220V |
