Airtac GV Slow Start Valve GV20008F2B
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow-Start Valve GV20008F2B Technical Specifications
- Model: GV20008F2B
- Type: 5/2-way pilot-operated with slow-start function
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 380g ±5% (excluding accessories)
- Dimensions: 52mm(W) × 90mm(L) × 56mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing operation)
- Flow rate: 850 l/min (ANR) at 0.5MPa
- Response time: ≤50ms (open), adjustable slow-release 0.1–3s (close)
- Protection class: IP67 (dust/water resistant)
- Endurance: ≥10 million cycles (at rated conditions)
Precision-engineered slow-start valve featuring progressive flow control during de-energization, preventing mechanical shock in sensitive systems. The dual-coil design ensures stable operation under voltage fluctuations. Equipped with manual override and position indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particles, oil content ≤1mg/m³).
- Clamping mechanisms in CNC machining centers
- Shock-sensitive material handling robots
- Plastic injection molding ejector systems
- Elevator door safety actuators
- Pharmaceutical blister packaging machines
Installation guidelines:
Mount horizontally with 15mm clearance below for solenoid maintenance.
Use vibration-damping brackets if ambient vibration exceeds 5G.
Lubricate with ISO VG32 turbine oil if air lubricator not present.
| Property | Property Value |
|---|---|
| sku | GV20008F2B |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
