Airtac GV Slow Start Valve GV20008JF1B
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow Start Valve GV20008JF1B Technical Details
- Model: GV20008JF1B
- Type: 5/3-way mid-position closed (slow start function)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.5W (standard), 0.8W (low power variant available)
- Response time: 50ms (activation), 0.5-3s adjustable slow start
- Flow rate: 850 L/min (ANR)
- Seal material: HNBR with wear-resistant coating
- Temperature range: -10℃ to 80℃ (anti-freeze option to -30℃)
- Protection rating: IP67 (dust/water resistant)
- Weight: 620g ±5% (with coil)
- Dimensions: 76mm(L) × 42mm(W) × 98mm(H)
- Port thread depth: 12mm (maximum engagement)
Precision-controlled slow start valve featuring gradual pressure buildup to prevent mechanical shock in pneumatic systems. The GV20008JF1B incorporates a unique dual-stage pilot mechanism with adjustable ramp time (via external needle valve), making it ideal for delicate load handling. Enhanced with copper-aluminum alloy body for heat dissipation and corrosion resistance.
- Robotic gripper pressure sequencing
- Medical bed/lift column actuation systems
- Glass/PV panel handling equipment
- Precision injection molding machines
- Food packaging line conveyor control
Operation guidance:
For optimal slow-start performance, maintain 0.5-1.0 MPa supply pressure differential.
Use ISO VG32 hydraulic oil mist lubrication if continuous cycling exceeds 5Hz.
Mounting orientation must have exhaust ports downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | GV20008JF1B |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/4 |
| Bracket Code | Without bracket |
| Coil Voltage | DC24V |
