Airtac GV Slow Start Valve GV20008JNA
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow-Start Valve GV20008JNA Technical Specifications
- Model: GV20008JNA
- Type: 5/3-way closed center (slow-start pneumatic valve)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Cv value: 1.8
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 340g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 55mm(H)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Response time: 50ms (initial actuation), 2-5s (full flow ramp-up)
- Protection rating: IP67 (dust/water resistant)
- Flow adjustment: Built-in adjustable needle valve (0.05-0.5L/min)
Precision slow-start valve with progressive flow control, featuring anti-water hammer design and copper-free aluminum alloy body. The integrated pilot-operated mechanism enables smooth actuator movement with 3-position memory function (center block). Requires 5μm filtered air with ISO 8573-1:2010 class 4.2.3 standards.
- Packaging machine clamp control (prevents sudden gripping)
- Medical bed/lift column positioning systems
- Automated assembly line pick-and-place units
- Semiconductor wafer handling robots
- Elevator door safety mechanisms
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction. Use locking nuts with 1.5-2Nm torque.
Perform monthly lubrication (ISO VG32 oil mist) for high-cycle applications (＞500k operations/year).
| Property | Property Value |
|---|---|
| sku | GV20008JNA |
| Pressure Gauge Code | Without attached table |
| Port Size | PT1/4 |
| Bracket Code | Without bracket |
| Coil Voltage | AC220V |
