Airtac HD4A Pneumatic Valve HD4A110
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A110 Pneumatic Valve Technical Specifications
- Model: HD4A110 (Base model with standard coil)
- Valve type: 5-port 3-position closed center (double solenoid)
- Port configuration: 1/4" BSPP (G1/4) with NPT optional
- Operating pressure range: 0.05–1.0 MPa (7–145 PSI)
- Maximum flow rate: 1,200 NL/min (Cv=2.4)
- Voltage variants: DC12V/24V, AC110V/220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 56mm(W) × 38mm(H) × 98mm(L)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Response time: ≤25ms (at 0.5MPa)
- Protection class: IP67 (coil)/IP40 (valve body)
- Manual override: Built-in push-button (optional lockable)
The HD4A110 features a modular design with ISO 5599-1 interface compatibility, enabling quick system integration. Its low-hysteresis spool mechanism ensures precise directional control in continuous cycling applications. The aluminum alloy body with hard anodized treatment provides enhanced corrosion resistance for humid environments.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery tension regulation systems
- Semiconductor wafer handling robots
- Beverage filling station pneumatic circuits
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use flexible tubing for vibration isolation in high-cycle applications (>5Hz).
Lubricate with ISO VG32 turbine oil if operating below 0℃.
| Property | Property Value |
|---|---|
| sku | HD4A110 |
