Airtac HD4A Pneumatic Valve HD4A120
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A120 Pneumatic Valve Technical Specifications
- Model: HD4A120
- Type: 5/2-way single/double solenoid (monostable or bistable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 320g ±5g (with coil)
- Dimensions: 60mm(L) × 45mm(W) × 75mm(H)
- Seal material: Heat-resistant NBR (Nitrile) rubber
- Temperature range: -20℃ to 80℃ (non-freezing)
- Flow capacity: CV 1.8 (Kv 1.56) @ 0.5MPa
- Response time: ≤25ms (actuation/deactuation)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in mechanical override button
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual pressure balance structure, featuring gold-plated pins for enhanced corrosion resistance. The optimized spool design achieves 50% faster response than standard models. Includes LED status indicator and surge protection circuitry. Compatible with ISO 15407-1 standards.
- Automated production line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- Semiconductor handling equipment
- Automotive assembly clamping systems
- Food processing pneumatic circuits (oil-free version available)
Installation guidelines:
Mount in vibration <5m/s² environments. Use M3x10 screws (torque ≤0.4Nm).
Maintain 15mm clearance below valve for exhaust dispersion. Lubricate with ISO VG32
turbine oil if operating below -10℃. Replace seals after 5 million cycles.
| Property | Property Value |
|---|---|
| sku | HD4A120 |
