Airtac HD4A Pneumatic Valve HD4A130C
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A130C Pneumatic Valve Technical Specifications
- Model: HD4A130C
- Type: 5-port 3-position closed center (Pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 1.6W (DC), 2.2VA (AC)
- Weight: 680g ±5% (including coil)
- Dimensions: 57mm(W) × 47mm(H) × 123mm(L)
- Seal materials: HNBR/Nitrile rubber (standard), FKM/Viton (optional)
- Temperature range: -5℃ to 80℃ (with silicone grease lubrication below 0℃)
- Flow capacity: 750 L/min (ANR) at 0.5MPa
- Response time: ≤30ms (exhaust to center position)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring optimized spool geometry for reduced pressure loss. The aluminum alloy body with hard anodized finish ensures corrosion resistance in humid environments. Integrated surge suppression protects solenoid coils from voltage spikes. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Multi-axis pneumatic actuator control in assembly lines
- Plastic injection molding machine clamp mechanisms
- Material handling systems with cylinder sequencing
- Automated packaging equipment with safety interlocks
- Robotic welding cell tooling positioners
Installation requirements:
Mount with M5 screws (max torque 2.5N·m). Maintain 0.5-1.0mm clearance between manifold surfaces.
For vertical mounting, position exhaust ports downward to prevent debris accumulation.
Always install after F.R.L. units (Filter-Regulator-Lubricator).
| Property | Property Value |
|---|---|
| sku | HD4A130C |
