Airtac HD4A Pneumatic Valve HD4A210
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A210 Pneumatic Valve Technical Details
- Model: HD4A210
- Type: 5/2-way single solenoid (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Flow capacity: 850 L/min (Cv=1.2)
- Weight: 320g ±5% (including coil)
- Dimensions: 62mm(L) × 42mm(W) × 83mm(H)
- Body material: Reinforced PBT resin
- Seal material: NBR/FKM (optional)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Response time: ≤20ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with optimized internal flow path design, featuring 25% faster response than standard models. The corrosion-resistant construction and dual-chamber sealing system ensure leak-free operation in humid environments. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Textile machinery cylinder control
- Bottle filling station diverters
Installation guidelines:
Mount with M5 screws (max torque 2.5N·m). Maintain 15mm clearance
below valve for maintenance access. Use pulse-width modulation
(PWM) drivers for voltage variations exceeding ±10%.
