Airtac HD4A Pneumatic Valve HD4A220
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A220 Pneumatic Valve Technical Specifications
- Model: HD4A220
- Type: 5/2-way single solenoid control (double solenoid optional)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO228/ISO6149 compliant
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Max operating frequency: 5 cycles/second
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Effective flow area: 17.5mm² (Cv=0.98)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Fluid temperature: -20℃ to 70℃
- Seal material: Heat-resistant NBR (HNBR) with PTFE coating
- Body material: Anodized aluminum alloy (ADC12)
- Weight: 450g ±3% (without connectors)
- Dimensions: 64mm(L) × 42mm(W) × 95mm(H)
- Port configuration: 5 ports (2 output, 2 exhaust, 1 supply)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in emergency push button
The HD4A220 features a balanced spool design with low starting pressure (0.15MPa) capability, making it ideal for low-pressure pneumatic systems. Its dual-chamber sealing structure ensures zero leakage during standby. The valve incorporates surge protection circuitry and is compatible with SMD mounting for automated assembly processes. Requires 5μm filtered dry air with ISO8573-1:2010 Class 3.4.3 air quality.
- High-speed sorting equipment with rapid cylinder cycling
- Plastic injection molding machine ejector systems
- Automated welding fixture clamping sequences
- Textile machinery thread tension control
- Beverage canning line pneumatic diverters
Installation guidelines:
Mount in vibration-free environment with ≤0.5mm alignment tolerance.
Maintain ≥15mm clearance on exhaust ports for proper venting.
Lubrication recommended every 5 million cycles using ISO VG32 turbine oil.
