Airtac HD4A Pneumatic Valve HD4A230C
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A230C Pneumatic Valve Technical Details
- Model: HD4A230C
- Type: 5-port 3-position closed center (Double solenoid)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage options: DC12V/24V, AC110V/220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.3)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 620g ±2%
- Dimensions: 54mm(L) × 44mm(W) × 108mm(H)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement 9mm)
- Max cycling rate: 5Hz (300 cycles/min)
High-flow directional control valve with center-block function, featuring low power consumption (≤2.8W) and metal body construction. Designed for complex pneumatic circuits requiring mid-position cutoff. Includes manual override and surge suppression. Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 3.4.2).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Material handling cylinder sequencing
- Textile machinery tension control
- Food processing equipment with washdown requirements
Installation guidelines:
Mount horizontally with exhaust ports downward. Use vibration-resistant brackets
for machinery exceeding 15Hz operation. Lubricate every 2M cycles (ISO VG32
turbine oil recommended). Allow 20mm side clearance for heat dissipation.
| Property | Property Value |
|---|---|
| sku | HD4A230C |
