Airtac HD4V Solenoid Valve HD4V110A
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110A Solenoid Valve Technical Specifications
- Model: HD4V110A
- Type: 4V series 5-port/3-position closed center (double solenoid)
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.2–0.8 MPa (29–116 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 520g ±5% (with connector)
- Dimensions: 123mm(L) × 54mm(W) × 50mm(H) (excluding fittings)
- Seal materials: NBR standard (FKM optional for high temp)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Maximum flow rate: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection class: IP67 (dust/water resistant)
- Mounting style: Direct acting with ISO 4400 interface
- Manual override: Optional mechanical override button
- Lubrication: Oil-less operation (compatible with ISO VG32 lubricated air)
High-flow directional control valve featuring center-block design for precise mid-position cylinder control. The HD4V110A incorporates dual coil protection with LED status indicators and surge suppression circuitry. Its reinforced polymer coil housing resists chemical corrosion in harsh environments. Requires 5μm filtered compressed air with ≤5mg/m³ oil content.
- Automated assembly line positioning systems
- Injection molding machine clamp control
- Robotic arm end-effector actuators
- Plastic extrusion equipment
- Automotive brake testing rigs
- Bottle capping machinery
Installation guidelines:
Maintain horizontal mounting position (±15° tolerance). Use shock-absorbing
brackets in high-vibration environments. Allow 20mm clearance below valve
for electrical connector access. Pre-charge system to ≥0.3MPa before initial
energization.
| Property | Property Value |
|---|---|
| sku | HD4V110A |
| Standard Voltage | AC220V |
