Airtac HD4V Solenoid Valve HD4V110CI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V110CI Solenoid Valve Technical Details
- Model: HD4V110CI
- Type: 5/2-way monostable (single solenoid) with spring return
- Port configuration: 1/4" BSPP (G1/4) with 5 ports (P, A, B, EA, EB)
- Operating pressure range: 0.2–1.0 MPa (extended range for heavy-duty use)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (pressurized), ≤35ms (exhaust)
- Flow capacity: CV 1.2 (Kv 1.4) at 0.5MPa
- Seal materials: HNBR/Nitrile compound (enhanced oil resistance)
- Temperature tolerance: -10℃ to 80℃ (with dry air), -10℃ to 60℃ (with lubricated air)
- Body material: Reinforced PBT with glass fiber (UL94 V-0 rated)
- Protection class: IP67 (dustproof & temporary immersion protection)
- Weight: 520g ±3% (including coil and connectors)
- Dimensions: 78mm(L) × 48mm(W) × 102mm(H) (excluding manifold mounting surface)
- Port thread depth: 12mm (minimum engagement required)
High-flow directional control valve engineered for industrial automation systems requiring rapid cycling and precise actuator control. Features dual-pressure operation capability (0.2MPa minimum for reliable pilot operation) and shock-resistant coil design. Optimized spool geometry reduces "stiction" effect in high-humidity environments. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Pneumatic cylinder sequencing in automotive assembly lines
- High-speed sorting gates in packaging machinery
- Clamping control for CNC machining centers
- Dusty environment operations (cement batch plant actuators)
- Plastic injection molding machine ejector systems
Installation protocol:
Mount on ISO 5599/1 compliant manifold using M5 mounting screws (2.5Nm torque limit).
Maintain ≥15mm clearance from adjacent valves for heat dissipation.
Always install downstream air filter regulator (F.R.L. unit) with 40μm filtration.
Critical note:
For AC voltage models, maximum allowable continuous energization time is 85% duty cycle.
Use surge suppressor (VDR/Zener diode) when controlling via PLC outputs.
| Property | Property Value |
|---|---|
| sku | HD4V110CI |
| Standard Voltage | AC 110V |
