Airtac HD4V Solenoid Valve HD4V120AI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V120AI 4-Way Pneumatic Solenoid Valve Technical Specifications
- Model Identification: HD4V120AI
- Valve Configuration: 5-port/4-way (1 inlet, 2 outlets, 2 exhausts)
- Operation Type: Double solenoid with spring return (bi-stable)
- Port Thread Size: G1/2" (BSPP) with ISO 228 standard
- Effective Sectional Area: 32mm² (Cv=1.8)
- Pressure Range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage Variants: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Coil Insulation: Class F (155℃ rated)
- Power Consumption: 4.5W (DC)/5.2VA (AC)
- Seal Material Configuration: HNBR main seals with FKM backup rings
- Ambient Temperature: -5℃ to 80℃ (with 0℃ anti-freeze measures)
- Fluid Compatibility: Filtered air (ISO 8573-1:2010 Class 3.4.2)
- Body Material: Aluminum ADC12 with chromate conversion coating
- Protection Rating: IP67 (coil)/IP40 (valve body)
- Shock Resistance: 30G acceleration (11ms duration)
- Vibration Resistance: 10–150Hz @ 2.0mm amplitude
- Weight: 1,250g ±3% (including coil and accessories)
- Dimensions: 178mm(L) × 82mm(W) × 123mm(H) (manifold mounting surface excluded)
Industrial-grade 4-way pneumatic valve featuring dual manual override and LED status indicator. Optimized for high-cycle applications with 10 million+ mechanical cycles rating. Incorporates arc suppression circuit for coil protection and surge-resistant design for unstable power environments. Requires 5–50μm filtration with automatic drain.
- Plastic injection molding machine clamp units
- Automated assembly line pallet changers
- CNC rotary table positioning systems
- Lithium battery formation equipment actuators
- Automotive brake testing pneumatic circuits
Mounting protocol:
Requires horizontal installation with manifold torque 12–15N·m.
Maintain 20mm clearance below exhaust ports for muffler installation.
Perform 500-cycle run-in before full load operation.
| Property | Property Value |
|---|---|
| sku | HD4V120AI |
| Standard Voltage | AC220V |
