Airtac HD4V Solenoid Valve HD4V130CAI
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CAI Solenoid Valve Technical Details
- Model: HD4V130CAI (4V series high-flow variant)
- Function type: 5/2-way double solenoid control
- Operation: Double electric pilot with manual override
- Port size: G1/2" (BSPP thread standard)
- Effective area: 130mm² (valve core diameter)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: AC110V/50-60Hz, AC220V/50-60Hz (±10%)
- Power consumption: AC: 4.5VA (max), Inrush: 25VA
- Flow capacity: CV=2.3 (Kv=2.0) @7bar
- Response time: ≤30ms (exhaust to actuation)
- Seal materials: Main seal HNBR, auxiliary seals FKM
- Temperature range: -10℃ to 60℃ (with anti-condensation measures)
- Protection class: IP67 (dust/water resistant)
- Weight: 850g ±3% (including coil assembly)
- Dimensions: 120mm(L) × 75mm(W) × 45mm(H)
- Electrical connection: DIN43650 Form A (standard)
- Port alignment: ISO 5599-1 standard mounting pattern
High-performance industrial solenoid valve with dual-coil configuration for precise directional control in demanding pneumatic systems. Features hardened brass body with electroless nickel plating (5-8μm thickness) for corrosion resistance. Designed for 1 million+ cycle durability with ≤0.1% leakage rate at maximum pressure. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Plastic injection molding machine clamp controls
- Automated assembly line cylinder sequencing
- Textile machinery air circuit switching
- CNC tool changers with rapid cycling needs
- Food processing pneumatic actuators (FDA-compliant versions available)
Installation requirements:
Maintain horizontal mounting position (±15° tolerance) with vibration damping pads.
Use copper-free anti-seize compound on threads. Minimum 20mm clearance required
below valve for exhaust port maintenance. Pre-charge pilot circuit for optimal
response in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | HD4V130CAI |
| Standard Voltage | AC220V |
