Airtac HD4V Solenoid Valve HD4V130CE
Category: Solenoid Valves | Brand: Airtac | Series: HD4V
AirTAC HD4V130CE 5/2-Way Solenoid Valve Technical Details
- Full model code: HD4V130CE-02 (base model with standard coil)
- Valve type: 5/2-way pilot-operated (double solenoid)
- Port thread: G1/8 (BSPP) with ISO 228-1 standard
- Effective sectional area: 18mm² (Cv≈1.3)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V±10%, DC24V±10%, AC110V±15%(50/60Hz), AC220V±15%(50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.8W (DC)/3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (-5℃ to 80℃), optional FKM available
- Body material: Reinforced PBT with glass fiber
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 270g ±5% (with coil)
- Dimensions: 59mm(L) × 36mm(W) × 78mm(H) (excluding connectors)
- Port positions: 5 ports (P:1, A:2, B:4, EA:5, EB:3)
High-flow directional control valve with dual-coil latching capability, featuring optimized flow paths for reduced pressure drop. The corrosion-resistant construction incorporates brass end plates and stainless steel springs, supporting 5 million cycle durability. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with ≤5mg/m³ oil mist content.
- Double-acting cylinder control in automated assembly lines
- Pneumatic clamping systems for CNC machining centers
- Packaging machinery sequence control
- Textile equipment cylinder reversing
- Semiconductor handling robot end effectors
Installation guidelines:
Mount in vibration-free environment with manifold base torque ≤1.5N·m.
Maintain 15mm clearance around solenoid for heat dissipation.
Use surge suppressor for AC coils in high-frequency switching (>5Hz).
| Property | Property Value |
|---|---|
| sku | HD4V130CE |
| Standard Voltage | AC24V |
