Airtac HFCI 2-Jaw Pneumatic Gripper HFCI16
2、Integrated anti-collision pad on piston front end effectively reduces metal-on-metal impact noise during jaw release;
3、Dowel pin holes at base ensure improved installation accuracy and consistent positioning during repeated disassembly/reassembly;
4、High repeatability (±0.01mm) in clamping operation ensures reliable performance for automated equipment integration;
5、Comprehensive range of series and specifications accommodates diverse workpiece geometries, meeting varied application requirements.
Category: Pneumatic Grippers , Brand: AIRTC , Series: HFCI
AirTAC HFCI16 Two-Jaw Pneumatic Gripper Technical Details
- Model: HFCI16
- Type: Double-acting parallel gripper
- Bore size: Ø16mm
- Operating pressure: 0.1–0.7 MPa (14.5–101.5 PSI)
- Stroke per jaw: 8mm (total 16mm opening)
- Gripping force: 24–168N (variable with pressure)
- Port size: M5x0.8 (standard), adapters available for 1/8" NPT
- Repeat accuracy: ±0.02mm
- Material: Anodized aluminum body, stainless steel guide rods
- Seals: NBR (nitrile) standard, optional FKM for high temp
- Temperature range: -10℃ to 80℃ (NBR), -10℃ to 150℃ (FKM)
- Weight: 210g ±5g
- Dimensions: 70mm(L) × 34mm(W) × 38mm(H)
- Mounting pattern: 25mm inter-hole spacing (M4 threaded)
- Response time: 0.1s (at 0.5MPa)
Precision-engineered parallel gripper with dual piston design for symmetrical force distribution. Features T-slot compatibility for tooling attachments and integrated air cushioning to minimize part-shock during high-speed operations (≥1.5m/s). Requires 40μm filtered, lubricated air (ISO 8573-1).
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- CNC machine tending robots
- Optical lens handling systems
- Miniature bearing assembly stations
Operation tip:
For fragile objects, reduce operating pressure to 0.15–0.3MPa and
install external shock absorbers. Lubricate guide rods monthly in
continuous duty cycles. Avoid lateral loads exceeding 10N.
- AGM10 series compact gripper mount
- APV-2 precision pressure regulator
- ASD-02 magnetic sensor kit
- Special jaw plates (order separately by material: PU/PTFE/Al)
| Property | Property Value |
|---|---|
| sku | HFCI16 |
| Operation Type | Double Acting |
| Gripper Optional Types | Two Claws |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
