Airtac HFCI 2-Jaw Pneumatic Gripper HFCI32
$209.34
Regular price
$216.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFCI32
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、The internal wedge mechanism delivers enhanced clamping force;
2、Integrated anti-collision pad on piston front end effectively reduces metal-on-metal impact noise during jaw release;
3、Dowel pin holes at base ensure improved installation accuracy and consistent positioning during repeated disassembly/reassembly;
4、High repeatability (±0.01mm) in clamping operation ensures reliable performance for automated equipment integration;
5、Comprehensive range of series and specifications accommodates diverse workpiece geometries, meeting varied application requirements.
Category: Pneumatic Grippers , Brand: AIRTC , Series: HFCI
Operational guidance:
For optimal performance, use filtered air (5-40μm) with 1-2 drops of ISO VG32 oil per m³.
Regular lubrication intervals: every 500,000 cycles. Avoid lateral overload beyond 30N.
2、Integrated anti-collision pad on piston front end effectively reduces metal-on-metal impact noise during jaw release;
3、Dowel pin holes at base ensure improved installation accuracy and consistent positioning during repeated disassembly/reassembly;
4、High repeatability (±0.01mm) in clamping operation ensures reliable performance for automated equipment integration;
5、Comprehensive range of series and specifications accommodates diverse workpiece geometries, meeting varied application requirements.
Category: Pneumatic Grippers , Brand: AIRTC , Series: HFCI
AirTAC HFCI32 Dual-Actuator Pneumatic Gripper Specifications
- Model: HFCI32
- Type: Parallel twin-paddle gripper (double-acting)
- Gripping force: 98N @ 0.6MPa
- Stroke per jaw: 20mm (±10mm adjustable)
- Operating pressure: 0.1–0.7 MPa
- Port size: M5x0.8 (dual ports for push/pull action)
- Repeat accuracy: ±0.1mm
- Body material: Anodized aluminum alloy (A6063-T5)
- Paddle material: Hardened stainless steel (SUS304)
- Seal type: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃ (extended to 120℃ with HS seals)
- Weight: 1.2kg (including mounting hardware)
- Dimensions: 120mm(L) × 50mm(W) × 60mm(H)
- Max operating speed: 500mm/s
- Shock resistance: 15G (3ms duration)
- Mounting pattern: 32mm inter-hole spacing (M4 threaded)
High-precision parallel gripper with dual piston chambers for synchronized jaw movement. Features through-hole piston design preventing side-load wear, with integrated shock absorbers for high-cycle applications. Compatible with ISO 9400-1 mounting standards.
Typical Applications:
- Robotic arm end-effectors for CNC machine tending
- PCB board handling in electronics assembly
- Precision component sorting systems
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
Operational guidance:
For optimal performance, use filtered air (5-40μm) with 1-2 drops of ISO VG32 oil per m³.
Regular lubrication intervals: every 500,000 cycles. Avoid lateral overload beyond 30N.
Configuration options:
- Optional magnetic sensor slots (M5/M8 connector)
- Custom paddle lengths available (15-50mm)
- Anti-vibration kits for high-speed applications
- ESD-safe version for semiconductor handling
| Property | Property Value |
|---|---|
| sku | HFCI32 |
| Operation Type | Double Acting |
| Gripper Optional Types | Two Claws |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
