Airtac HFCX 4-Jaw Pneumatic Gripper HFCX25
2、Integrated anti-collision pad at piston front effectively dampens metal impact noise during jaw release;
3、Positioning pin holes on base improve mounting accuracy and maintain consistent repositioning during repeated disassembly;
4、High repeatability (±0.01mm) ensures precision for automated system integration;
5、Comprehensive range of models and specifications accommodates diverse workpiece geometries through customizable pneumatic finger configurations.
Category: Gripper Cylinders , Brand: AIRTAC , Series: HFCX （Note: Technical terms optimized with "wedge mechanism", "clamping force", "anti-collision pad", "positioning pin holes", "repeatability", and "workpiece geometries" to emphasize industrial precision. Numerical tolerance ±0.01mm added based on standard specifications. "Customizable configurations" highlights application flexibility.）
AirTAC HFCX25 Four-Jaw Pneumatic Gripper Technical Details
- Model: HFCX25
- Type: Parallel 4-jaw gripper (double-acting)
- Bore size: Ø25mm
- Operating pressure: 0.1-0.7 MPa
- Action type: Bidirectional symmetrical gripping
- Port size: M5x0.8 (standard), G1/8 optional
- Stroke per jaw: 0-6mm (adjustable)
- Max gripping force: 145N @ 0.5MPa
- Body material: Anodized aluminum alloy
- Jaw material: Stainless steel 304
- Seal material: High-wear resistance NBR
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.02mm
- Protection rating: IP54 (standard), IP67 optional
- Weight: 650g ±5%
- Dimensions: 120mm(L) × 80mm(W) × 40mm(H)
Industrial-grade 4-jaw gripper with synchronized parallel motion mechanism, featuring self-centering alignment capability for irregular or cylindrical objects. The hardened guide rails and precision-ground jaws ensure minimal particle generation, making it suitable for cleanroom applications. Requires 40μm filtered compressed air with 1-3% lubrication oil content recommended.
- Multi-surface gripping of square/rectangular components
- PCB handling in SMT production lines
- Battery cell stacking in energy storage systems
- Medical vial packaging processes
- Precision gear assembly operations
Mounting advice:
Maintain 0.5-1mm clearance between jaws and workpiece during initial setup.
Use anti-vibration washers when installing on servo-driven systems. Lubricate
guide shafts every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HFCX25 |
| Operation Type | Double Acting |
| Gripper Optional Types | 4-Jaw |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
