Airtac HFCY 3-Jaw Pneumatic Gripper HFCY20
2、Anti-collision cushion integrated at piston end effectively reduces metal-on-metal impact noise during jaw release;
3、Precision positioning pin holes on base enhance installation accuracy and maintain consistent repositioning during repeated disassembly;
4、Superior gripping repeatability (±0.01mm) optimized for automated equipment integration;
5、Multiple series configurations with diversified specifications available for handling varying workpiece geometries.
Category: Pneumatic Grippers | Brand: Airtac | Series: HFCY
AirTAC HFCY20 Three-Jaw Pneumatic Gripper Specifications
- Model: HFCY20
- Type: Parallel three-jaw gripper (double-acting)
- Bore size: 20mm
- Stroke per jaw: 4mm (standard), customizable up to 12mm
- Operating pressure: 0.1–0.7 MPa
- Max gripping force: 120N @0.5MPa
- Repeat accuracy: ±0.05mm
- Body material: Anodized aluminum alloy
- Piston material: Hardened stainless steel
- Seal type: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 420g ±5%
- Dimensions: 124mm(L) × 82mm(W) × 48mm(H)
- Port size: M5 × 0.8 (dual ports for push/pull action)
- Mounting: 4×M4 threaded holes on base
- Air consumption: 17.5cm³/stroke
High-precision three-finger gripper with synchronized parallel motion, featuring wear-resistant guides and adjustable gripping force. The HFCY20's unique wedge mechanism ensures equal force distribution across all jaws, making it ideal for handling fragile or irregularly shaped objects. Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- PCB component insertion in electronics assembly
- Bottle cap positioning in packaging lines
- Precision gear handling in automotive manufacturing
- Semiconductor wafer transfer systems
- 3C product testing equipment
Operation tip:
For optimal performance, maintain 0.1-0.15mm clearance between jaw tips and workpiece.
Use shock absorbers when cycling >2Hz. Lubricate guide rails every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | HFCY20 |
| Operation Type | Double Acting |
| Gripper Optional Types | Three-Jaw |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
