Airtac HFK Guided Parallel Type Pneumatic Gripper HFK10
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK10 Technical Details
- Model: HFK10
- Type: Guided parallel pneumatic gripper (dual slide rail)
- Gripping force: 20-40N adjustable (at 0.5MPa)
- Stroke per finger: 0-10mm
- Operating pressure: 0.2-0.7 MPa
- Rail type: Dual linear ball bearings
- Repeatability: ±0.02mm
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (standard), NPT1/8 optional
- Material: Aluminum alloy body, hardened steel rails
- Weight: 220g ±5g
- Dimensions: 80mm(L) × 40mm(W) × 30mm(H)
- Seal material: NBR (nitrile) with grease retention design
- Max sliding speed: 500mm/s
- Mounting: 4x M3 threaded holes (depth 5mm)
The HFK10 precision guided gripper features dual hardened linear rails ensuring smooth parallel motion with minimal deflection. Its compact profile and anti-vibration structure make it ideal for high-speed automated systems requiring micron-level positioning accuracy. The through-hole design allows optional vacuum pickup integration.
- PCB component insertion machines
- Medical device assembly lines
- Watch movement handling systems
- Semiconductor wafer transfer
- Food-grade packaging (certified material version available)
Operational guidance:
For optimal performance, maintain air supply dew point below 3℃ and install a 5μm filter.
Lubricate rails every 500,000 cycles using ISO VG32 hydraulic oil. Avoid side-load forces exceeding 15N.
- Cycle life: 50 million operations (under standard load)
- Static friction: ≤0.5N
- Return spring force: 8N
- Air consumption: 15cm³/stroke (at 0.5MPa)
| Property | Property Value |
|---|---|
| sku | HFK10 |
| Gripper Optional Types | Standard Type |
| Opening/Closing Stroke | <4mm> |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
