Airtac HFK Guided Parallel Type Pneumatic Gripper HFK10B
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Pneumatic Gripper HFK10B Specifications
- Model: HFK10B
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø10mm
- Operating pressure: 0.05–0.7 MPa
- Max thrust: 16N (at 0.5MPa)
- Stroke per jaw: 4mm (standard)
- Guide rail type: Dual linear ball bearings
- Repeat accuracy: ±0.01mm
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, hardened steel guide rails
- Seal material: NBR rubber
- Port size: M5×0.8 (dual ports for push/pull action)
- Mounting: 2x M3 threaded holes (side/vertical mounting)
- Compatibility: ISO 6432 standard cylinders
- Weight: 250g ±5%
- Dimensions: 76mm(L) × 34mm(W) × 20mm(H)
Precision parallel gripper with integrated linear guides, designed for high-accuracy part handling. Features zero-backlash ball bearing guidance and dual air ports for balanced force distribution. The anodized surface provides corrosion resistance in humid environments. Requires 5μm filtered air with 1-3 drops of oil per m³.
- PCB component insertion machines
- Micro gear assembly systems
- Medical device manufacturing lines
- Precision calibration equipment
- Watch movement handling systems
Operation tip:
For delicate objects, use 0.1-0.3MPa pressure with flow control valves
to achieve smooth acceleration (recommended 50-100mm/s grip speed).
| Property | Property Value |
|---|---|
| sku | HFK10B |
| Gripper Optional Types | Side-mounted |
| Opening/Closing Stroke | <4mm> |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
