Airtac HFK Guided Parallel Type Pneumatic Gripper HFK10M
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK10M Guided Parallel Pneumatic Gripper Specifications
- Model: HFK10M
- Type: Guided parallel gripper (dual-piston design)
- Gripping force: 20-80N adjustable (at 0.5MPa)
- Stroke per jaw: 5mm standard (customizable 2-10mm)
- Operating pressure: 0.2-0.7 MPa
- Guide mechanism: Linear ball bearing slides
- Repeat accuracy: ±0.01mm
- Max operating speed: 150mm/s
- Port size: M5x0.8 (dual ports for push/pull control)
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (dust/water resistant)
- Weight: 0.25kg (excluding accessories)
- Dimensions: 80mm(L) × 30mm(W) × 40mm(H)
Precision guided gripper with dual linear guides for zero-rotation parallel movement, featuring anti-vibration design for high-speed operations. Integrated T-slot mounting system allows multi-position installation. Requires clean dry air (40μm filtration) with optional magnetic sensor compatibility.
- PCB component insertion robots
- Pharmaceutical blister packaging lines
- Micro-motor shaft handling systems
- Optical lens assembly stations
- 3C product testing equipment
Operation tip:
For precision gripping, maintain 0.1-0.3mm clearance between jaws and workpiece.
Use regulated lubrication (ISO VG32) every 500km of travel. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | HFK10M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Opening/Closing Stroke | <4mm> |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
