Airtac HFK Guided Parallel Type Pneumatic Gripper HFK16N
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Guided Parallel Gripper HFK16N Technical Details
- Model Series: HFK16N (Guided Parallel Type)
- Bore Size: Ø16mm
- Action Type: Double-acting
- Stroke per Jaw: 5mm standard (3mm/8mm optional)
- Gripping Force: 52N at 0.5MPa
- Operating Pressure: 0.1-0.7MPa
- Port Size: M5x0.8 (UNF1/8" adapter optional)
- Body Material: Anodized aluminum alloy
- Slide Rail Type: Dual linear guides with ball bearings
- Piston Seal: NBR rubber
- Temperature Range: -10℃ to 80℃
- Repeat Accuracy: ±0.02mm
- Weight: 430g ±2%
- Dimensions: 112mm(L) × 42mm(W) × 40mm(H)
- Mounting Pattern: 30mm × 22mm (4×M4 threaded holes)
- Max Travel Speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
Precision parallel gripper with integrated linear guides ensures minimal deflection during high-speed operations. The hardened steel rails and ball bearing system provide smooth movement and extended service life. Features symmetrical air ports for bidirectional control and optional cushioning adjustment.
- PCB component insertion machines
- CNC machine tool part changers
- Pharmaceutical blister packaging systems
- Precision bearing assembly stations
- 3C industry testing equipment
Operation Tip:
For optimal performance, maintain air supply dew point below 3℃ and install
a 5μm filter. Use regulated speed controllers (ASC-02 type) to prevent
impact damage during rapid cycling (>2Hz).
- Rod end styles: Flat pad, V-groove, or custom tooling plates
- Position sensing: Magnetic sensor slots (SM-6 compatible)
- Surface treatment: Standard anodized or nickel-plated version
| Property | Property Value |
|---|---|
| sku | HFK16N |
| Gripper Optional Types | Through-hole mounting type |
| Opening/Closing Stroke | <6mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
