Airtac HFK Guided Parallel Type Pneumatic Gripper HFK16R
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK16R Technical Specifications
- Model: HFK16R
- Type: Guided parallel pneumatic gripper (double-acting)
- Bore size: Ø16mm
- Max gripping force: 32N at 0.6MPa
- Stroke per finger: 8mm (standard), customizable up to 20mm
- Operating pressure: 0.2-0.7 MPa
- Port size: M5x0.8 (dual ports for push/pull action)
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Rail material: Hardened steel with chrome plating
- Seal type: NBR (Nitrile) standard, optional FKM/Viton
- Temperature range: -10℃ to 80℃ (NBR seals)
- Weight: 450g ±2%
- Dimensions: 102mm(L) × 34mm(W) × 28mm(H)
- Mounting pattern: 4x M4 threaded holes (12mm pitch)
- Max operating speed: 500mm/s
- Shock resistance: 50m/s² (10-55Hz vibration resistant)
Precision guided gripper with integrated linear rails ensuring parallel movement accuracy under lateral loads. Features dual piston design with symmetrical force distribution and zero backlash adjustment mechanism. Optional magnetic sensor slots (M5 mounting) for position feedback. Compatible with ISO 15552 mounting standards.
- PCB component insertion machines
- Automated syringe assembly in medical devices
- Precision gearbox part handling
- Battery cell stacking in EV manufacturing
- Optical lens positioning systems
- Watch component assembly lines
Operation tip:
For delicate object handling, use 0.3-0.4MPa pressure with silicone pads.
Lubricate rails every 500km travel distance using ISO VG32 pneumatic oil.
Avoid side impact forces exceeding 50N to maintain alignment accuracy.
| Property | Property Value |
|---|---|
| sku | HFK16R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Opening/Closing Stroke | <6mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
