Airtac HFK Guided Parallel Type Pneumatic Gripper HFK16W
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK16W Rail-Guided Parallel Type Pneumatic Gripper Specifications
- Model: HFK16W
- Type: Double-acting rail-guided parallel gripper
- Gripping force: 45N (at 0.5MPa)
- Stroke per jaw: 8mm (total 16mm opening)
- Operating pressure: 0.15–0.7 MPa
- Rail type: Linear ball bearing guidance
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Port size: M5 (standard) / NPT1/8 optional
- Material: Aluminum alloy body, stainless steel guide rails
- Seal material: NBR rubber
- Weight: 420g ±5g
- Dimensions: 200mm(L) × 50mm(W) × 40mm(H)
- Mounting pattern: 4x M4 threaded holes (16mm spacing)
- Max operating speed: 500mm/s
- Shock resistance: 15m/s² (with cushioning)
A precision parallel gripper with integrated linear guides, designed for high-speed pick-and-place operations requiring micron-level repeatability. Features wear-compensating design with adjustable gripping force via pressure regulation. The dual-rail structure minimizes angular deviation during operation, making it ideal for delicate part handling.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Watch movement assembly systems
- Optical lens handling in cleanrooms
- Battery cell sorting robots
Operation note:
For extended lifespan, use ISO VG32 hydraulic oil mist lubrication (0.3-0.5cc/min recommended).
Avoid lateral impact forces exceeding 50N. Regular rail cleaning every 500km of travel.
- Custom finger lengths available (5-50mm)
- Optional magnetic sensor (M9 connector)
- High-temp variant with FKM seals (up to 150℃)
- Anti-corrosion coating for humid environments
| Property | Property Value |
|---|---|
| sku | HFK16W |
| Gripper Optional Types | Side mount, narrow claw type |
| Opening/Closing Stroke | <6mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
