Airtac HFK Guided Parallel Type Pneumatic Gripper HFK20
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK20 Technical Details
- Model: HFK20
- Type: Guided parallel pneumatic gripper (double-acting)
- Gripping force: 30–100N adjustable (factory preset at 50N)
- Stroke per jaw: 0–20mm (total jaw opening 40mm)
- Operating pressure: 0.2–0.7 MPa
- Guiding system: Dual linear ball bearings with hardened steel rails
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (hard coat)
- Seal material: NBR (nitrile) standard / Optional FKM (fluorocarbon)
- Port size: M5x0.8 (dual ports for push/pull operation)
- Speed control: Built-in adjustable flow control valves (0–1.5 L/min)
- Mounting: 4x M4 threaded holes (bottom) + 2x M3 side holes
- Weight: 480g ±2%
- Dimensions: 100mm(L) × 42mm(W) × 32mm(H)
Precision-engineered parallel gripper with integrated linear guides, designed for high-accuracy pick-and-place operations. Features zero-backlash motion through preloaded bearings and corrosion-resistant surface treatment. Optional shock absorbers available for high-speed applications (>1m/s). Compatible with ISO 9400-1 mounting standards.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Optical lens handling systems
- Battery cell sorting robots
Installation guidance:
Apply thin-film lubricant (Molykote EM-30L recommended) on guide rails during initial setup.
Limit side load to <15% of maximum gripping force. Maintain ISO 8573-1:2010 Class 3 air quality.
| Property | Property Value |
|---|---|
| sku | HFK20 |
| Gripper Optional Types | Standard Type |
| Opening/Closing Stroke | <10mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
