Airtac HFK Guided Parallel Type Pneumatic Gripper HFK20F
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK20F Guided Parallel Gripper Specifications
- Model: HFK20F
- Type: Guided parallel gripper (double-acting)
- Gripping force: 20N at 0.5MPa
- Stroke per jaw: 0-8mm (adjustable)
- Operating pressure: 0.1-0.7 MPa
- Max repeat accuracy: ±0.01mm
- Guide mechanism: Precision linear ball bearings
- Piston material: Hard-anodized aluminum alloy
- Seal material: NBR (optional FKM)
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports for push/pull action)
- Weight: 250g ±5%
- Dimensions: 98mm(L) × 50mm(W) × 32mm(H)
- Mounting pattern: 4x M4 threaded holes (6mm depth)
- Shock resistance: 15G acceleration tolerance
- IP rating: IP54 (standard), IP67 optional
Precision-engineered parallel gripper with integrated linear guides, featuring zero backlash operation and wear compensation. The hardened steel rails and dual ball bearing blocks ensure smooth motion under lateral loads. Optimized flow channels enable 80ms open/close cycle times at 0.5MPa.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Robotic micro-assembly stations
- Optical lens handling systems
- CNC machine tool part changers
Installation tip:
Use alignment jigs during mounting to ensure parallel rail orientation.
Apply lithium-based grease every 500,000 cycles. Avoid side impact loads
exceeding 30N during operation.
- Static stiffness: 15N/μm
- Max lateral moment: 1.2Nm
- Air consumption: 15cm³/stroke
- Vibration resistance: 10-2000Hz @ 1.5mm amplitude
| Property | Property Value |
|---|---|
| sku | HFK20F |
| Gripper Optional Types | Bottom Mounting Type |
| Opening/Closing Stroke | <10mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
