Airtac HFK Guided Parallel Type Pneumatic Gripper HFK20N
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK20N Guided Parallel Pneumatic Gripper Specifications
- Model: HFK20N
- Type: Dual-guide rail parallel gripper (double-acting)
- Gripping force: 50N (adjustable via pressure regulation)
- Stroke per jaw: 0-12mm (total opening 24mm)
- Operating pressure: 0.2-0.7 MPa
- Guide rail type: Linear ball bearing system
- Repeat accuracy: ±0.02mm
- Port size: M5 (standard) with Rc1/8 adapter option
- Operating temperature: -10℃ to 80℃
- Body material: Anodized aluminum alloy (hard coat)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54 (dust protected & water splashed)
- Weight: 0.65kg ±3% (excluding accessories)
- Dimensions: 104mm(L) × 60mm(W) × 42mm(H)
- Mounting pattern: 30mm × 30mm ISO standard
- Lubrication: Pre-lubed (relubrication interval: 2000km travel)
Precision parallel gripper with dual hardened steel guide rails for zero-play operation. Features symmetrical force distribution and anti-twist design, optimized for high-speed pick-and-place (up to 3m/s). Includes shock-absorbing end caps and T-slot mounting grooves for flexible integration. Requires 5μm filtered air with ISO VG32 grade lubricant.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Silicon wafer handling robots
- Precision optical lens positioning
- Battery cell stacking systems
Operational tip:
Maintain 0.3-0.5MPa air pressure for optimal grip force balance.
Use parallel jaw approach mode when handling fragile items -
enable through PLC pulse control (minimum 0.1s dwell time).
| Property | Property Value |
|---|---|
| sku | HFK20N |
| Gripper Optional Types | Through-hole mounting type |
| Opening/Closing Stroke | <10mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
